EP Fabric



Spec.

Item		 Breaking
Strength≥
N/mm		 Breaking
Elongation
≤%		 Hot air shrinkage
150℃/30min
≤%		 Elongation at
10%
≤%		 Weight/
SQM
g/㎡		 Adhesive
Strength
≥N/mm
EP100 Warp 140 ≥14 5.5 1.5 355±20 7.8
Weft 55 ≤45 0.5
EP125 Warp 160 ≥14 5.5 1.5 425±20 7.8
Weft 65 ≤45 0.5
EP150 Warp 200 ≥14 5.5 1.5 520±20 7.8
Weft 70 ≤45 0.5
EP200 Warp 240 ≥15 5.5 1.5 620±20 7.8
Weft 80 ≤45 0.5
EP250 Warp 310 ≥15 5.5 1.5 760±20 7.8
Weft 90 ≤45 0.5
EP300 Warp 340 ≥15 5.5 1.5 860±30 7.8
Weft 85 ≤45 0.5
EP350 Warp 390 ≥15 5.5 2.0 1030±40 7.8
Weft 850 ≤45 0.5
EP400 Warp 450 ≥15 5.5 2.0 1180±50 7.8
Weft 90 ≤45 0.5




























We can manufacture the products according to the customer's requirements on specifications, width and length.
