NN Fabric




Spec.

Item		 Breaking
Strength≥
N/mm		 Breaking
Elongation
≤%		 Hot air shrinkage
150℃/30min
≤%		 Elongation at
10%
≤%		 Weight/
SQM
g/㎡		 Adhesive
Strength
≥N/mm
NN100 Warp 130 20 5.5 2.5 300±20 7.8
Weft 50 60 0.5
NN125 Warp 155 20 5.5 2.5 330±20 7.8
Weft 55 60 0.5
NN150 Warp 178 20 5.5 2.5 400±20 7.8
Weft 65 50 0.5
NN175 Warp 200 25 5.5 2.5 445±20 7.8
Weft 70 40 0.5
NN200 Warp 225 25 5.5 2.5 510±20 7.8
Weft 75 40 0.5
NN250 Warp 275 25 5.5 2.5 59±30 7.8
Weft 80 40 0.5
NN300 Warp 330 25 5.5 2.5 710±30 7.8
Weft 85 40 0.5
NN400 Warp 445 25 5.5 3.0 860±50 7.8
Weft 85 40 0.5




























We can manufacture the products according to the customer's requirements on specifications, width and length.
