Rubber Hose Fabric
| Item | 500D/2 | 840D/1 | 1000D/1 | 1000D/2 | 1000D/3 | 2000D/2 | 2000D/3 | 4000D/3 |
| Breaking strength per end≥ | 45N | 60N | 70N | 130N | 200N | 250N | 380N | 850N |
| Breaking elongation | ≥18% | 18±2% | 18±2% | 19±2% | 19±2% | 19±2% | 20±2% | 20±2% |
| Elongation at 22.6N | ≥3.5 | ≥5.0 | ≥4.0 | |||||
| Elongation at 44.1N | 4.0±2.0 | |||||||
| Elongation at 66.6N | 6.0±2.0 | |||||||
| Elongation at 88.1N | 4.0±2.0 | |||||||
| Elongation at100N | 4.0±2.0 | |||||||
| Elongation at 200N | 4.5±2.0 | |||||||
| Adhesive strength N/cm≥ | 40 | 40 | 50 | 98 | 108 | 120 | 140 | 140 |
| Hot air shrinkage 150℃ 30 minute≤ | 2.0% | 1.0% | 2.0% | 2.0% | 2.0% | 2.0% | 2.0% | 2.0% |
| Breaking strength Unevenness rate | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
| Elongation Unevenness rate≤ | 10 | 10 | 10 | 6 | 6 | 6 | 6 | 6 |
| Thicknessmm | 0.41±0.05 | 0.3±0.05 | 0.41±0.05 | 0.56±0.05 | 0.66±0.05 | 0.8±0.05 | 0.9±0.05 | 1.4±0.05 |
We can manufacture the products according to the customer's requirements on specifications, width and length.
