PRODUCTS
Dipped polyester soft cord
| Item | Unit | Soft Polyester Cord 1000D | |||||||
| 2X3 | 3X3 | 2X5 | 4X3 | 5X3 | 6X3 | 9X3 | 12X3 | ||
| Breaking strength | N | >440 | >640 | >740 | >850 | >1070 | >1280 | >1900 | >2500 |
| Breaking Elongation | % | 11±1.3 | 11.5±1.5 | 11.5±1.5 | 11.5±1.5 | 11.5±1.5 | 11.5±1.5 | 11.5±2.0 | 11.5±2.0 |
| Elongation | % | 150N | 200N | 200N | 300N | 300N | 400N | 500N | 500N |
| 2.9±0.5 | 2.5±0.5 | 2.3±0.5 | 2.8±0.6 | 2.4±0.6 | 2.5±0.6 | 2.3±0.6 | 1.7±0.6 | ||
| Diameter | mm | 0.9±0.1 | 1.2±0.1 | 1.24±0.1 | 1.36±0.1 | 1.55±0.1 | 1.65±0.1 | 2.1±0.15 | 2.4±0.15 |
| Weight | g/100m | 73±3.0 | 110±4.0 | 121±4.0 | 145±5.0 | 185±6.0 | 217±7.0 | 320±10.0 | 426±10.0 |
| Hot air shrinkage | % | 3.8±0.5 | 3.8±0.5 | 3.8±0.6 | 3.8±0.6 | 3.8±0.5 | 3.8±0.6 | 3.8±0.6 | 3.8±0.6 |
| Oil shrinkage | % | 4.0±0.5 | 4.2±0.5 | 4.2±0.6 | 4.2±0.6 | 4.4±0.5 | 4.4±0.6 | 4.5±0.6 | 4.5±0.6 |
| Adhesion | N/cm | ≥220 | ≥240 | ≥260 | ≥280 | ≥300 | ≥330 | ≥420 | ≥480 |
